Precision Display, Beyond Limits
Engineered for luxury vessels, this VA LCD display delivers high-contrast 65.32×32.82mm negative display with 1000cd/㎡ brightness. Featuring 0.25 viewing angle optimization, salt-spray resistance, and -30℃~80℃ operational range, it meets rigorous demands for yacht navigation and control systems.
Item No :
65.32×32.82 VA LCD Display For YachtOrder(MOQ) :
500 PiecesPayment :
TT TransferProduct Origin :
Anhui, ChinaSupplier Type :
ManufacturerLead Time :
About 20-25 days|
Main Parameters |
|
|
Module number |
GVH1001FFVL011-287A-29 |
|
Application |
Yacht |
|
Type |
COG |
|
LCD Type |
VA |
|
Active Area |
65.32*32.82 |
|
View angle |
0.25 |
|
Electrical Interface |
FPC |
|
Brightness |
1000cd/㎡ |
|
Outline dimension |
73.02*35.82±0.2 |
|
Backlight |
White |
|
Display mode |
Negative |
|
Operate temperature |
-30℃~ +80℃ |
|
Storage temperature |
-35℃~ +85℃ |
|
Power Supply Voltage |
VLED=3.0V@200mA, VLCD=5.0V |
|
Backlight lifetime |
One year |
Main features and benefits
Marine Environment Superiority
IP68 sealing withstands salt spray/wave immersion VA LCD display)
Sunlight Combat Technology
1000cd/㎡ brightness + negative VA mode ensures readability in tropical glare
Vibration & Shock Certified
Passes DNV-GL SHIP rules
Space-Optimized Design
73.02×35.82mm ultra-slim profile fits premium helm stations
Corrosion Defense System
316L stainless steel bezel resists seawater degradation
Recommend Products
Application scenarios
✅ Helm Control Panels（ VA LCD display）: Navigation data displays
✅ Engine Monitoring: RPM/fuel/temp status screens
✅ Entertainment Systems: Media control interfaces
✅ Cabin Automation: Climate/lighting control panels
✅ Safety Systems: Bilge pump/Fire suppression indicators
1. Deep foundation and strength guarantee: We have been deeply involved in the VA LCD display field for 30 years and have accumulated rich experience in production, manufacturing, and sales. This not only means mature and stable processes, but also represents a profound understanding of market demand and the ability to continuously innovate.
2. Vertical integration and controllable quality: The core advantage of Golden Vision lies in its ability to self produce throughout the entire industry chain. We have achieved independent production of everything from the core LCD display screen to the critical PCBA (printed circuit board components). This deep vertical integration ensures full quality control from the source to the finished product, effectively ensuring product consistency and reliability
Significantly shorten delivery time and enhance supply chain resilience.
3. Business team, one-stop service: We have a strong team of professional engineers with full technical capabilities covering the entire process from low-level hardware design to high-level software development. Whether it's professional software and hardware engineers solving technical problems, UI design teams creating intuitive and easy-to-use user interfaces, or structural engineering teams ensuring product durability and perfect compatibility, JinShiShi can provide you with comprehensive, one-stop technical support and solutions from concept to mass production.
Anhui Golden Vision Optoelectronics, with 30 years of craftsmanship, full industry chain self-produced strength, and top cross disciplinary engineering team, is committed to becoming your most trusted display technology partner, helping your products stand out in the fierce market competition!
