Precision Display, Beyond Limits
Designed for industrial data display, this character STN display delivers crisp 2004-character dot matrix (70.4×20.8mm) with transflective polarizer. Featuring ZEBRA connector interface, 5V operation, and -20℃~70℃ thermal stability, it provides reliable alphanumeric readouts for control panels and instrumentation.
Item No :
Golden Vision Character STN DisplayOrder(MOQ) :
500 PiecesPayment :
TT TransferProduct Origin :
Anhui, ChinaSupplier Type :
ManufacturerLead Time :
About 20-25 days
|
Main Parameters |
|
|
Module number |
GVLCM2004BB-797A-13 |
|
Type |
COB |
|
LCD Type |
STN |
|
Dot pitch |
0.05*0.05 |
|
Active Area |
70.4*20.8 |
|
View angle |
6:00 |
|
Polarizer Type |
Transflective |
|
Pixel Arrangement |
Dot matrix |
|
Electrical Interface |
ZEBRA |
|
Brightness |
200 |
|
Outline dimension |
93*55 |
|
Backlight |
LED |
|
Display mode |
Positive |
|
Operate temperature |
‘-20℃～+70℃ |
|
Storage temperature |
‘-30℃～+80℃ |
|
Power Supply Voltage |
VDD=5V |
|
Backlight lifetime |
20,000 hours |
|
Power consumption |
≤80mA |
|
Package |
Anti-static blister tray |
Main features and benefits
Industrial-Grade Construction
COB (Chip-on-Board) technology enhances shock/vibration resistance vs. COG(character STN display)
All-Light Condition Readability
Transflective polarizer maintains visibility in sunlight (200cd/m²) and darkness (LED backlight)
Simplified Integration
ZEBRA elastomer connector enables tool-free assembly and vibration-proof contact
Energy Efficient Operation
≤80mA low power consumption at 5V for battery-backed systems
Long-Term Reliability
20,000-hour backlight lifespan with anti-static packaging for ESD protection
Recommend Products
Application scenarios
✅ Industrial Control Panels(character STN display): Production line status monitors
✅ Test & Measurement: Multimeter/data logger readouts
✅ Medical Devices: Patient monitor parameter displays
✅ POS Systems: Transaction information screens
✅ Embedded Controllers: Equipment diagnostic interfaces
1. Deep foundation and strength guarantee: We have been deeply involved in character STN display field for 30 years and have accumulated rich experience in production, manufacturing, and sales. This not only means mature and stable processes, but also represents a profound understanding of market demand and the ability to continuously innovate.
2. Vertical integration and controllable quality: The core advantage of Golden Vision lies in its ability to self produce throughout the entire industry chain. We have achieved independent production of everything from the core LCD display screen to the critical PCBA (printed circuit board components). This deep vertical integration ensures full quality control from the source to the finished product, effectively ensuring product consistency and reliability
Significantly shorten delivery time and enhance supply chain resilience.
3. Business team, one-stop service: We have a strong team of professional engineers with full technical capabilities covering the entire process from low-level hardware design to high-level software development. Whether it's professional software and hardware engineers solving technical problems, UI design teams creating intuitive and easy-to-use user interfaces, or structural engineering teams ensuring product durability and perfect compatibility, JinShiShi can provide you with comprehensive, one-stop technical support and solutions from concept to mass production.
Anhui Golden Vision Optoelectronics, with 30 years of craftsmanship, full industry chain self-produced strength, and top cross disciplinary engineering team, is committed to becoming your most trusted display technology partner, helping your products stand out in the fierce market competition!
